Description

Linton Instrumentation Tissue Bath Stations

The Linton Tissue Bath Station was designed to overcome many of the flaws of traditional tissue bath set-ups. Improvements include:-

A sturdy base with self-adjusting feet to ensure a stable operating environment. Small footprint – small enough to fit inside a fume cupboard.
Easy tissue mounting – the whole transducer/tissue bearer assembly lifts out of the bath to allow the tissue to be easily attached to both bearer and transducer externally.
Interchangeable baths – Linton Tissue Baths are available in three styles and sizes from 5ml to 50ml, they can be quickly and easily replaced thanks to the quick-release brackets and screw-on tubing connectors fitted to all Linton Tissue Bath Stations.
Easily adjustable components – the transducers/verniers, tissue bearer and sleeving can all be moved independently of one another.
Colour co-ordinated tubing design – perfusate, water jacket heating water, overflow, waste and gas tubes are all colour coded for easy identification.
Expandable – the design of the system allows for connecting systems in series reducing the cost of doubling-up on other lab equipment such as water heater/circulator baths.
Optional Addenbrookes style, side gassing chamber baths – idea for small tissue preparations. Gassing occurs in a side chamber away from the main chamber where the tissue is located. This avoids measurement artefacts which can occur when carbogen bubbles hit the tissue preparation. The side chamber also ensures extremely good perfusate/compound mixing.

Linton Tissue Bath Station Models.
Part No.	Description	Available Bath Sizes
LIN1	4 Channel Tissue Bath Station. Comes with Perspex stand, 4 x Addenbrookes Style – side chamber baths, 4 x heat exchangers, 4 x tissue bearers, tubing and connectors.	5ml and 10ml.

LIN2	4 Channel Tissue Bath Station. Comes with Perspex stand, 4 x Standard Style – single chamber baths, 4 x heat exchangers, 4 x tissue bearers, tubing and connectors.	5ml, 10ml, 20ml, 25ml and 50ml.

LIN3	4 Channel Tissue Bath Station. Comes with Perspex stand, 4 x Superfusion Baths fitted with Pt stimulation electrodes, 4 x heat exchangers, 4 x tissue bearers, tubing and connectors.	N/A

Tissue Bath Station Options.
Part No.	Description	Suitable for:
Pt Stimulation Electrode Assembly	Includes: Tissue bearer, adjustable electrode mounting block, 2 x Pt stimulation electrodes, thumb screws, leads.
		LIN1 and LIN2
Fitted Perfusate Reservoir	Specially designed to fit the Linton Tissue Bath Stations. Either single or dual perfusate reservoir/s (each 5L volume). Optional station mounting kit, Perspex lid (with slot for gassing stick) and gassing stick.
		All
Spares	Available spares include:
	Tissue Baths (all sizes and styles).
	Heat Exchangers.
	Pt Stimulation Electrodes.
	Stopcocks.
	Bath mounting clamps.
	Tubing connectors.

Note: we can also supply custom glassware to suit your specification. Please contact us for details.

We also supply single tissue baths (to fit laboratory scaffolding) in sizes from 5ml to 50ml. As well as our own tissue bath stations, we supply other systems for all applications including single and dual channel stand-alone stations, complete
with built-in heater/circulators etc.. ideal for teaching applications.

We offer a wide range of :-

Transducers for force (Isometric) and displacement (isotonic) anywhere to suit all budgets.
Electrical Stimulators.
Specialist baths for electrophysiology.
Custom glassware.
Stimulation electrodes.
Data acquisition, archive and analysis.
Pen / thermal-array recorders.
Vernier Micromanipulators for fine adjustment of tension.
